General Specifications

65k jpg

The range of- high quality firearms made by Auguste Francotte comprise of. three types:

Sidelock Shotguns and double barreled rifles made by Auguste Francotte:

The side locks system is more advanced than others. The advantages which it gives are numerous. The external firing mechanism gives stronger action and produces guns which are very robust. Double sear and an independent hammer mechanism make the gun using this lock system very safe when in use. The speed of firing, together with very precise adjustment from the trigger pull and great reliability, make it particularly attractive for the hunter or sport shooter. These guns are manufactured according to very close tolerances, by our highly skilled workers, produces a top quality gun, the value of which will always continue to increase.

Auguste Francotte shotguns and double-barreled rifles with the Anson system

This mechanism is less intricate than the side locks system, however, retaining the qualities of safety and finish of a high grade gun, it allows the production of a strong gun for a lower price than a gun with the side locks mechanism.

Auguste Francotte repeating rifle with the bolt action system

This model is specially designed for stalking and tracking. It is a top quality rifle and its price is quite reasonable when taking into account the care involved in the selection of the raw materials, assembly and adjustment. The stock, which is available to the owner's personal requirements, provides an incomparably balanced gun tailor-made for the hunter. Additionally, it is available in a great range of caliber's.

Matched pairs - of guns

We specialize in the manufacture of matched pairs of guns. With these guns, not only are the wooden parts matched, but, the general technical characteristics are identical in terms of weight, boring of the barrels, yield and balance, etc.

General specifications:

Smooth bore guns 12-16-20-28, and .4I0 gauge.

Chokes sizes of smooth bore guns:
Any combination of choke dimensions can be specified
Smooth bore guns chambers 2 3/4" (70 mm) or 3" (76 mm).

Rifles calibers:

Francotte Anson System Francotte Sidelock System Francotte Bolt Action
.243
7x57R
7.65R
8x57JRS
9.3x74R
.243
7x57R
7.65R
8x57JRS
.270
30.06
.308
.300 W.M.
.338 W.M.
9.3x74R
.375 H&H
.458W.M.
.243
.270
7x64
30.06
.308
.300 W.M.
.338W.M.
7mm R.M.
.375 H&H
.458W.M.

Other caliber's, medium/magnum or African caliber's available upon request.

Barrels:

Ejectors:
A great developmet on smooth barreled guns and on double-barreled rifles. Special extractor for rimmed cartridges on our double barreled rifles.

Actions:
Auguste Francotte Chrome nickel steel. There are eight different types depending upon the caliber and model.

Sidelock Mechanism:
Auguste Francotte type with BAR action side locks for smooth bore guns. With back action side lock system for double-barreled rifles.

Trigger:

Safety catch:
Automatic or free.

Stock:
Straight or pistol, according to order. In selected walnut, the wood can be made available according to the choice of the client.

Forend:

Checkering:
Deluxe checkering.

Finishing:
Actions - case hardened grey, colored or black. Wood - fully by hand oil treated.

Other Options:

Weight:
Shotguns:
12 gauge game gun +/- 3 kg/ 6.61 lbs

Double-barreled rifles:
Medium caliber's t 3.5 kg/ 7.61 lbs
Magnum caliber's 5 kg/ 11.1 lbs

Security and longevity:
Above, we have described the main characteristics of firearms manufactured by Auguste Francotte. Nevertheless our efforts to achieve perfection leave no stone unturned. To make sure that our double barreled guns and rifles have the maximum strength and longest possible life, the actions are adapted to the caliber. This is the reason why, in order to reinforce the action, our double-barreled rifles are equipped with back action side lock mechanisms. The side locks with frontal spring is used on our smooth bore guns

In the interest of security of the user and for the reliability of our guns, we reinforce the stocks on African caliber rifles by an extension of the tang. The grip is equipped with a finely decorated cap, beneath which is. located a spare front sight. This can be available on all models of our rifles as an optional extra.

Testing:
All our guns are tested for performance and precision. Our smooth bore hunting guns are fired at 35 meters or 40 yards on 75cm diameter targets, with hunting shot shells (# 6 shot). The client can always specify, if he or she desires, the make of the cartridge and the range at which he wishes the gun to be tested. For double barreled rifles, it is essential because of the considerable differences between various makes of ammunition, that the rifle is regulated with the type of ammunition required by the client. The range must also be specified. It is not recommended to change from one type of cartridge to another without first trying it out by some target practice.

Scope mounts:
The fitting of scopes is possible on all our rifles. We would ask the client to mention this at the time of ordering his rifle. (To ensure proper stock dimensions for use with a telescopic sight.) If fitting a scope to a bolt action rifle, is quite simple, it is much more delicate on a double-barreled rifle because it necessitates some work on the barrels, which is the only way to get the accuracy, It is therefore advisable to state this, when ordering.

Standard Butt
Dimensions
Hunting
Gun
Pigeon Shooting
Gun
Double Barreled
Rifle
Repeating
Rifle
mminchesmminchesmminchesmminches
Length3811538115368.514.5368.514.5
Drop at comb381 1/2321 1/4401 9/16401 9/16
Drop at heel602 3/8381 1/2652 9/16652 9/16
Pitch5129.53/8512602 3/8
Cast off/on4-63/16 -1/44-63/16 -1/44-63/16 -1/44-63/16 -1/4

You have decided to buy a good quality gun, manufactured by A. Francotte; choosing the correct model is consequently an important part of your decision. The type of use to which your gun is destined, whether for hunting or sporting, are the essential factors.

To secure detailed information and price estimates, please drop us a not via the doublegunshop.com information request form
